CD 1175: France

16 3/8" X 1 3/6"  (414mm X 35mm)



FOLEMBRAY

No 683



Picture courtesy Michel Tirand

16 1/2" X 1 3/6"  (417mm X 37mm)



No markings (unmarked EIV)





Picture courtesy Michel Tirand

16 5/8" X 1 3/6"  (420mm X 37mm)



EIV

D4



Picture courtesy Michel Tirand

16 3/8" X 1 3/6"  (414mm X 35mm)



FOLEMBRAY

D4



Picture courtesy Michel Tirand

Plate: 16 5/8" X 1 3/6"  (420mm X 37mm)

Insert: 7 3/4" X 10" (198mm X 255mm)



EIV 129

{Note: This includes an insert to provide further protection to the wire that is cemented to the plate}





Picture courtesy Michel Tirand

16 3/8" X 1 3/6"  (415mm X 38mm)



ISOREX

4258



Picture courtesy Michel Tirand

16 1/2" X 1 3/6"  (417mm X 35mm)



L'ELECTRO VERRE

D4

(sandblast) LEV-T



Picture courtesy Michel Tirand



These unusual insulators were designed to support a wire or bus bar as it passed through a substation wall.
